ComNet CopperLine Value Kit: Point-to-Point Mini Ethernet-over-Coax Extender
The ComNet CopperLine Ethernet-over-coax minis are an ultra-small form factor addition to the ComNet CopperLine product family. These miniature remote units provide 10/100 Mbps Ethernet data over extended distance coaxial cable, up to 1,200 feet (400 meters). The mini CopperLine units will allow extended distance over copper to be used in standard applications where space is extremely limited. A DIP Switch allows configurable selection of 10 Mbps or 100 Mbps speed these units are simple to install. This CopperLine Value kit provides two units with power supplies.
Product Type: Network Extender
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Brand Name: ComNet
Compatibility:
- Retrofit existing analog CCTV installations to Ethernetbased systems
- CCTV systems for casinos, airports, school campuses
Length: 2.3"
Manufacturer: ACRE
Product Name: CopperLine Value Kit: Point-to-Point Mini Ethernet-over-Coax Extender
Product Line: CopperLine
Manufacturer Part Number: CLEK11EOC
Manufacturer Website Address: http://www.acre-co.com
Packaged Quantity: 2
Limited Warranty: 5 Year
Additional Information:
- Transmits individual Ethernet data over Coaxial cable
- Extends Ethernet up to 1,200 feet (400 m) over Coaxial cable
- Temperature operation from -0°C to +50°C
- Full 10/100 Mbps Bandwidth
- Supports Multicast, Unicast and Jumbo Frame
- Symmetric Bandwidth provides consistent upload and download with virtually zero packet loss over the total usable distance
- Type tested to RFC-2544 TCP/IP network bandwidth packet transmission standards
- User-selectable data rate for maximum bandwidth and transmission distance utilization
- Complies with all major IEEE standards and RFC network protocols for UDP, TCP/IP, HTTP/HTTPs
- Designed and manufactured in the USA
- LED status indicators confirm operating status
- Can be DIN-rail mounted with optional DINBKT4 mounting kit
