ComNet Commercial Grade 100Mbps Media Converter with 48V POE, Mini, SFP Required
The ComNet™ CWMCFE(X)POE/M Series 2-port media converters provide full-duplex fiber optic transmission of a single channel of 10/100 Mbps Ethernet data (10/100 BASE-TX) through multimode or single mode optical fiber. Type ST, SC or SFP optical connectors are available. They provide full compliance with IEEE 802.3at as Power Sourcing Equipment(PSE), with a maximum power of 30 watts in Mode A or Mode B, making them ideal for those applications where the remote equipment draws significant power. A higher output 60 watt model is available. Mode A and mode B are selected by the media converter automatically. The Ethernet electrical interface auto-negotiates to either 10 or 100 Mbps without the need for any user selection, and the optical interface operates at 100 Mbps (100-FX). Packaged in a rugged, compact sized housing, these units are designed for shelf or stand-alone mounting, or may be DIN-rail mounted by the addition of ComNet model DINBKT2 Adaptor plate kit. LED indicators are provided for rapidly ascertaining the operating status of the device. A power supply providing 48 VDC at 1.25A is provided with each converter. Plug-and-play design ensures ease of operation, and no optical adjustments are ever required.
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- With 100Base-X technology get up to 100Mbps data transfer rate over twisted pair cable
- The Rail-mountable provides convenient installation
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Country Of Origin: United States
Brand Name: ComNet
Form Factor: Desktop
Manufacturer: ACRE
Product Model: CWMCFESFPPOE30/M
Product Name: Commercial Grade 100Mbps Media Converter with 48V POE, Mini, SFP Required
Manufacturer Part Number: CWMCFESFPPOE30/M
Manufacturer Website Address: http://www.acre-co.com
Limited Warranty: 5 Year
