ComNet 8-Port Managed Gigabit Switch
The ComNet™ CNGE8MS Managed Redundant Ring Ethernet Switch provides robust transmission of four (4) 10/100/1000BASE-T(X) and four (4) gigabit combo ports. The four combo ports are 10/100/1000Mbps configurable for either CAT5-e copper, or multimode or single-mode optical fiber by the use of optional ComNet SFPs. The exclusive ComNet ComRing (C-Ring) protects mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. Open-Vision, a powerful, easy-to-use Windows-based utility, allows the CNGE8MS to be centrally managed. Redundant DC inputs are included for uninterrupted operation in the event of a loss of operating power or a power supply failure. Diverse media selection allows for easy implementation of point-to-point, linear add-drop, drop-and-repeat, star, or true self-healing ring and mesh network system architectures. The electrical ports support the 10/100/1000Mbps Ethernet IEEE 802.3 protocol, and auto-negotiating and auto-MDI/MDIX features are provided for simplicity and ease of installation. These network- managed layer 2 switches are optically (100/1000BASE-FX) and electrically compatible with any IEEE 802.3 compliant Ethernet device. Unlike most Ethernet switches, these environmentally hardened units are designed for direct deployment in difficult out-of-plant or roadside operating environments. These units are DIN-Rail or wall-mountable
- Expand your network capacity with the help of 8 networking ports and transfer your data quickly and easily
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- No need to deal with power supply issues, the switch comes with a separate AC adapter to power up the unit
Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: RoHS
Brand Name: ComNet
Form Factor: Wall Mountable
Manufacturer: ACRE
Product Model: CNGE8MS
Product Name: 8-Port Managed Gigabit Switch
Manufacturer Part Number: CNGE8MS
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- 8-Port Managed Gigabit Switch
- ComRing Tool CD
Limited Warranty: Lifetime
Weight (Approximate): 2.43 lb
