ComNet 4-Channel Video Transmitter (1310 nm)
The ComNet FVT/FVR41 multiplexer simultaneously transmits four channels of video over one optical fiber utilizing state-of-the-art digital encoding and decoding for high-quality video transmission. These environmentally hardened units are ideal for use in unconditioned roadside or out-of-plant installations. These units are completely transparent to and universally compatible with any NTSC, PAL, or SECAM CCTV camera systems.
Features for FVT/FVR41 Series
- Digitally encoded video transmission, transmits 4 real-time color video signals on one optical fiber
- Exceptionally low video distortion with zero Performance Variation vs. Optical Path Loss
- Wide optical dynamic range: optical attenuators are never required
- NTCIP compatible
- Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40 to +75C ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
- Robust design ensures extremely high reliability in unconditioned out-of-plant environments
- Automatic resettable solid-state current limiters
- Status indicating LEDs provide rapid indication of critical operating parameters.
- Five year warranty
- Made in the USA
- Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
- Compatible with NTSC, PAL, or SECAM Video Standards
- Standard ComFit models are hot-swappable.
- ComFit standard form factor is designed for wall, surface, rack, or DIN rail mount installations (using optional card cage or DIN mounting bracket).
Product Type: Video Extender Transmitter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Taa Compliant: Yes
Country Of Origin: United States
Product Series: FVT/FVR41(M,S)1
Brand Name: ComNet
Form Factor: Rack-mountable
Manufacturer: ACRE
Product Model: FVT41S1
Product Name: 4-Channel Video Transmitter (1310 nm)
Manufacturer Part Number: FVT41S1
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- 4-Channel Video Transmitter (1310 nm)
- DC Plug-in Power Supply, 90-264 VAC, 50/60 Hz
Limited Warranty: 5 Year
