ComNet CWGE2FE8MSPOE Ethernet Switch
The ComWorx™ CWGE2FE8MSPOE Managed Ethernet Switch provides eight ports of 10/100 BASE-TX PoE and two ports of 10/100/1000TX or 100/1000FX transmission. These units are available for use with either conventional CAT-5e copper or optical transmission media. The eight electrical ports support the 10/100 Mbps Ethernet IEEE 802.3 protocol, and auto-negotiating and auto-MDI/ MDIX features are provided for simplicity and ease of installation. All eight ports support IEEE.802.3af based POE (Max total PoE budget is 77W). Two ports are 10/100/1000 configurable for copper or fiber media for use with multimode or single mode optical fiber, selected by optional SFP modules. These network managed layer 2 switches are optically (100/1000 BASE-FX) and electrically compatible with any IEEE 802.3 compliant Ethernet devices. Plug-and-play design ensures ease of installation, and no electrical or optical adjustments are ever required. The CWGE2FE8MSPOE incorporates LED indicators for monitoring the operating status of the managed switch and network. One switch, or two switches positioned side-by-side, can be mounted within any standard 19-inch equipment rack using the ComNet RMB Rack Mount Bracket Adaptor Kit (sold separately).
- Expand your network capacity with the help of 8 networking ports and transfer your data quickly and easily
- Electrical power is transmitted along with data in a single cable to devices such as Access Points, IP cameras or IP phones
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Rack mounting enables you to organize wires & secure cables for professional installation
Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: WEEE
Brand Name: ComNet
Form Factor: Rack-mountable
Manufacturer: ACRE
Product Model: CWGE2FE8MSPOE
Product Name: CWGE2FE8MSPOE Ethernet Switch
Manufacturer Part Number: CWGE2FE8MSPOE
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- CWGE2FE8MSPOE Ethernet Switch
- Power Supply
Limited Warranty: 5 Year
Weight (Approximate): 5 lb
