Broadcom MegaRAID 9560-8i PCIe Gen 4.0 RAID Controller
The MegaRAID 9560-8i is a high-performance PCIe Gen 4.0 x8 RAID-on-Chip controller engineered for enterprise servers requiring advanced storage flexibility. Built on the Broadcom SAS3908 architecture, this tri-mode adapter delivers twice the performance of previous-generation RAID controllers while supporting SAS, SATA, and NVMe storage in a single unified solution. Ideal for data centers, virtualization environments, and mission-critical applications demanding reliable, scalable storage management with maximum throughput and minimal latency.
Key Features
- PCIe Gen 4.0 x8 interface for maximum bandwidth and reduced bottlenecks
- Broadcom SAS3908 RAID-on-Chip (RoC) architecture for optimized performance
- Tri-mode storage support: SAS, SATA, and NVMe connectivity in one adapter
- Multiple RAID levels (0, 1, 5, 6, 10, 50, 60) for flexible data protection strategies
- Up to 2x performance improvement over previous-generation RAID controllers
- Enterprise-grade reliability with advanced error correction and monitoring
- Optimized for modern server environments and virtualization platforms
- Reduced power consumption with efficient PCIe Gen 4.0 design
Technical Specifications
| Specification |
Details |
| Manufacturer |
Strategic Sourcing (Broadcom) |
| Part Number |
LSI9560-8I |
| Product Name |
MegaRAID 9560-8i |
| Interface |
PCIe Gen 4.0 x8 |
| Controller Chip |
Broadcom SAS3908 |
| Storage Modes |
Tri-mode: SAS, SATA, NVMe |
| RAID Levels Supported |
0, 1, 5, 6, 10, 50, 60 |
| Architecture |
RAID-on-Chip (RoC) |
| Performance Gain |
2x vs. previous generation |
Frequently Asked Questions
What storage types does the MegaRAID 9560-8i support?
The MegaRAID 9560-8i is a tri-mode RAID controller supporting SAS, SATA, and NVMe storage devices simultaneously. This flexibility allows organizations to mix storage technologies within the same system, optimizing cost and performance based on workload requirements.
How does PCIe Gen 4.0 improve RAID controller performance?
The PCIe Gen 4.0 x8 interface provides double the bandwidth of PCIe Gen 3.0, enabling the MegaRAID 9560-8i to deliver up to 2x performance improvement. This reduces latency and maximizes throughput for high-demand storage operations in enterprise environments.
Which RAID levels are available on this adapter?
The MegaRAID 9560-8i supports comprehensive RAID levels including 0, 1, 5, 6, 10, 50, and 60. This range allows IT teams to select optimal data protection and performance configurations for diverse workloads from high-speed databases to redundant backup systems.
Is the MegaRAID 9560-8i suitable for virtualization environments?
Yes, the Broadcom SAS3908 RAID controller is optimized for modern server environments including virtualization platforms. Its RAID-on-Chip architecture and tri-mode connectivity make it ideal for hypervisor deployments requiring reliable, high-performance storage management.
