Brainboxes 4 Port RS422/485 Ethernet to Serial Adapter
Ethernet to Serial device server providing access to four RS422/485 serial ports. Data transfer rates up to 1,000,000 baud rates, coupled with 1Mbit/s line drivers deliver uncompromising performance. Our ES range provides simple instant networked serial ports. RS485 - 1 twisted pair - half duplex configuration with autogating provides trouble free data transmission due to automatic control of data direction. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.
- Power supply included with screw fix connector (5-30V DC)
- Serial Port Tunneling (individually configurable) allows serial cable replacement over any distance, no software required
- LED status indication
- Optional DIN rail mounting kit
- IP-30 rated enclosure
- Web configuration and RFC2217 compliant interface
- 10/100Base TX Ethernet port
- User friendly interface, simple to use, powerful in operation
- Max baud rate 1,000,000 1 MegaBaud
- 4 port RS422/485
Product Type: Multiport Serial Adapter
Environmentally Friendly: Yes
Environmental Certification: WEEE
Taa Compliant: Yes
Country Of Origin: United Kingdom
Brand Name: Brainboxes
Form Factor: Wall-mountable
Manufacturer: Brainboxes Limited
Product Model: ES-346
Product Name: 4 Port RS422/485 Ethernet to Serial Adapter
Manufacturer Part Number: ES-346
Manufacturer Website Address: http://www.brainboxes.com
Package Contents:
- 4 Port RS422/485 Ethernet to Serial Adapter
- Installation CD including Manual
- Microsoft Signed Drivers & Utilities
Limited Warranty: Lifetime
Thickness: 4.8"
Weight (Approximate): 1.54 lb
