Brainboxes 2 Port RS232 Low Profile PCI Express Serial Card
PCI Express Card providing two RS232 serial ports. Low profile board gives first serial port on the bracket, with a second serial port on a fly lead. Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, delivers uncompromising performance on your PC. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows 2000, XP, Server 2003, Vista, Server 2008, Windows 7 and Windows 8.
- Lifetime Warranty (registration required)
- Lifetime Support
- Sample programs, test & terminal software
- Drivers for all popular operating systems
- Up to 921,600 Baud
- DB9 connector (9 pin Male)
- PCI Express x1, x4, x8 x16 lane slots socket size
- 128 Byte tx and 128 Byte Rx FIFos
- 2 port RS232
Product Type: Serial Adapter
Environmentally Friendly: Yes
Environmental Certification: RoHS
Card Height: Low-profile
Taa Compliant: Yes
Country Of Origin: United Kingdom
Brand Name: Brainboxes
Form Factor: Plug-in Card
Manufacturer: Brainboxes Limited
Product Name: 2 Port RS232 Low Profile PCI Express Serial Card
Manufacturer Part Number: PX-101
Manufacturer Website Address: http://www.brainboxes.com
Package Contents:
- 2 Port RS232 Low Profile PCI Express Serial Card
- Installation CD Including Manual
- Microsoft Signed Drivers & Utilities
Limited Warranty: Lifetime
Weight (Approximate): 1.69 oz
