This Fast Ethernet media converter is perfect for network administrators, data center managers, and IT professionals who need reliable fiber ethernet connectivity for extending network segments over long distances. Our Black Box LHC212A delivers:
-
20km transmission range over singlemode fiber at 1310nm wavelength
-
10/100BASE-TX to 100BASE-FX conversion bridging copper and fiber networks
-
Singlemode fiber support for long-distance enterprise connectivity
-
Reliable network extension for campus and WAN applications
Key Features
-
Dual-speed operation supporting 10Mbps and 100Mbps Fast Ethernet
-
Singlemode 1310nm transmission optimized for 20km distances
-
Copper to fiber conversion extending network reach beyond copper limitations
-
Standards compliance meeting 10/100BASE-TX and 100BASE-FX specifications
-
Compact desktop design for easy deployment and installation
Technical Specifications
| Manufacturer |
Black Box Corporation |
| Model Number |
LHC212A |
| Type |
Fast Ethernet Media Converter |
| Copper Interface |
10/100BASE-TX RJ-45 connector |
| Fiber Interface |
100BASE-FX SC connector |
| Fiber Type |
Singlemode at 1310nm wavelength |
| Transmission Distance |
Up to 20km over singlemode fiber |
| Data Rate |
10/100 Mbps auto-negotiation |
| Applications |
Campus networks, WAN extension, fiber backbone connectivity |
Frequently Asked Questions
Q: How does this converter integrate with existing fiber ethernet switches?
A: This 100BASE-FX compatible converter seamlessly connects to fiber ethernet switches via SC connectors, enabling copper-to-fiber network extension for enterprise backbone and campus connectivity applications.
Q: What applications benefit from 20km singlemode transmission?
A: Long-distance fiber connectivity is ideal for campus networks, building-to-building links, metropolitan area networks, and WAN connections requiring reliable data transmission beyond copper cable limitations.
Q: Is this suitable for server rack network installations?
A: Yes. Compact form factor and SC connector compatibility make it perfect for server rack deployments, providing fiber connectivity for servers, switches, and storage systems requiring long-distance network connections.
Q: What makes singlemode 1310nm optimal for this application?
A: 1310nm wavelength provides excellent transmission characteristics over singlemode fiber with minimal signal loss, ensuring reliable 100Mbps performance across the full 20km distance specification for enterprise networking applications.
Fast Ethernet media converter Black Box LHC212A with 10/100BASE-TX to 100BASE-FX conversion, singlemode 1310nm, 20km transmission for network extension.
