Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell
Axiom 540-BBRN-AX. Host interface: PCIe, Output interface: Fiber, Expansion card standard: PCIe 3.0. Product colour: Black, Chrome, Green, Cooling type: Passive. Data transfer rate (max): 40 Gbit/s. Linux operating systems supported: Kernel 2.6.33,RedHat EL Linux 7.0, Server operating systems supported: SUSE Linux Enterprise Server 12,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2, Other operating systems supported: FreeBSD,VMware ESX/ESXi 5.1. Width: 13 mm, Depth: 68 mm, Height: 165 mm
The Axiom QSFP+ PCIe 3.0 x8 40Gbs Fiber Network Adapter is designed for Servers and high-end appliances. They offer simple integration into any PCI Express X8 to 40 Gigabit Networks. Based on Intel XL710AM Ethernet controller with two fully integrated Gigabit Ethernet Media Access Control (MAC) and XLPPI Interfaces, the Axiom QSFP+ NIC cards are the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers.
General Information
Manufacturer
Axiom Memory Solutions
Manufacturer Part Number
540-BBRN-AX
Manufacturer Website Address
http://www.axiommemory.com
Brand Name
Axiom
Product Name
40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Product Type
40Gigabit Ethernet Card
UPC
840177848803
Chipset
Chipset Manufacturer
Intel
Height
6.5"
Width
0.5"
Depth
2.7"
Weight (Approximate)
4.96 oz
Miscellaneous
Package Contents
40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Full Height Mounting Brackets
Half Height Mounting Brackets
Warranty
Limited Warranty
3 Year
