Description
- 2nd generation AMD Ryzen AM4 processors maximize connectivity and speed with NVMe M.2, USB 3.1 Gen2 and Gigabit LAN
- Military-grade TUF components like TUF LANGuard, TUF Chokes, TUF Capacitors, and TUF MOSFETs maximize durability
- TUF Protection with SafeSlot and Overvoltage protection ensures component stability and dependability
- Unmatched personalization with ASUS exclusive Aura Sync RGB lighting and additional RGB header
AMD B450 ATX gaming motherboard with Aura Sync RGB LED lighting, DDR4 3466MHz support, 32Gbps M.2, HDMI 2.0b, Type C and native USB 3.1 Gen 2.
- GPU Temperature Sensing & Fan Xpert 4 Core: Ensures every fan achieves the best balance of cooling performance and acoustics
- TUF Protection: SafeSlot, ESD Guards, DDR4 overvoltage protection, Digi+ VRM, and stainless-steel back I/O for long-term reliability
- Military-grade TUF Components: TUF LANGuard, TUF Chokes, TUF Capacitors, and TUF MOSFETs for maximum durability
- Exclusive DTS® Custom audio: Delivers positional cues to stereo headphones, helping you to pinpoint enemies and action
- Aura Sync RGB: Synchronize LED lighting with a vast portfolio of compatible PC gear
ARM YOUR BATTLESTATION
TUF Gaming motherboards are specially designed and tested to survive and thrive in conditions where other boards would struggle. Engineered with highly durable components, these motherboards deliver unwavering stability for gaming sessions that last as long as you demand.
When you build with a TUF Gaming motherboard, you also benefit from the TUF Gaming Alliance — an ASUS collaboration with trusted industry partners that ensures easier building, the best compatibility, and complementary aesthetics from components to case.
1. TUF MOSFETs
4. USB Type-C™ port
7. TUF Gaming Armor
10. DIGI+VRM & EPU
13. 32Gb/s M.2
SATA & PCIE x4 mode
16. Front USB 3.1 Gen 1
4. USB Type-C™ port
7. TUF Gaming Armor
10. DIGI+VRM & EPU
13. 32Gb/s M.2
SATA & PCIE x4 mode
16. Front USB 3.1 Gen 1
2. TUF Chokes
5. HDMI
8. PCI Express 3.0 Slot
CFX Support
ASUS SafeSlot
11. DDR4 3466(O.C.)
14. AMD B450 Chipset
5. HDMI
8. PCI Express 3.0 Slot
CFX Support
ASUS SafeSlot
11. DDR4 3466(O.C.)
14. AMD B450 Chipset
3. TUF Caps
6. USB 3.1 Gen 2 Ports
9. Realtek® ALC 887
Exclusive DTS Custom for Gaming headsets
‧ TUF Gaming Audio Cover
‧ Audio Shielding
‧ Dedicated audio PCB layers
‧ Premium Japanese audio capacitors
12. AMD AM4 Socket
15. SATA 6Gb/s ports
6. USB 3.1 Gen 2 Ports
9. Realtek® ALC 887
Exclusive DTS Custom for Gaming headsets
‧ TUF Gaming Audio Cover
‧ Audio Shielding
‧ Dedicated audio PCB layers
‧ Premium Japanese audio capacitors
12. AMD AM4 Socket
15. SATA 6Gb/s ports
TUF GAMING ALLIANCE
TUF Gaming Alliance is the marque of collaboration between ASUS and major PC-component manufacturers, including trusted brands like Antec®, Apacer®, Ballistix, Cooler Master®, Corsair®, Deepcool, Enermax, G.Skill, GeIL®, In Win, Scythe, SilverStone, Team Group and XPG. A growing range of compliant parts, from PC chassis and power supplies to CPU coolers and DRAM, guarantee both compatibility and aesthetic harmony. We're also continually increasing our partnerships to make the TUF Gaming Alliance ever stronger.
TUF PROTECTION
SAFESLOT
Protect your graphics card investment
SafeSlot is the PCIe slot reinvented by ASUS and engineered to provide superior retention and shearing resistance. Manufactured in a single step using a new insert-molding process, SafeSlot integrates fortifying metal for an inherently stronger slot, which is then firmly anchored to the PCB through additional solder points.
LAN PORT
ESD TVS diode protection on the LAN Circuit.
ESD TVS diode protection on the LAN Circuit.
KEYBOARDS AND MOUSE CONNECTORS
Additional on-circuit ESD transient-voltage-suppression.
Additional on-circuit ESD transient-voltage-suppression.
VGA PROTECTION
Additional on-circuit ESD TVS diodes to protect D-Sub functionality.
Additional on-circuit ESD TVS diodes to protect D-Sub functionality.
USB CONNECTORS
TVS diode for surface-mount and dual-inline package.
TVS diode for surface-mount and dual-inline package.
DIGI+ VRM
Precision control for stable power
The Digi+ VRM voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth and ultra-clean power delivery to the CPU at all times.
DRAM OVERVOLTAGE PROTECTION
Short-circuit damage prevention
Onboard resettable fuses prevent overcurrent and short-circuit damage. This extends beyond I/O ports to DRAM to safeguard the lifespan of your system and connected devices.
STAINLESS-STEEL BACK I/O
3X-better corrosion resistance
TUF's corrosion-resistant stainless-steel back I/O panels are bonded with chromium oxide ― so they can endure a 72-hour salt-spray test, compared to the industry standard of just 24 hours.
TUF COMPONENTS
TUF CHOKES
Certified military-grade TUF chokes deliver rock-steady power to the CPU, helping to improve system stability.
TUF CAPACITORS
+20% temperature tolerance and 2.5X-longer lifespan.
TUF MOSFETS
Certified military-grade MOSFETs with lower RDS(on)*.
*Lower RDS(on) results in better power efficiency and reduced heat generation.
TUF LANGuard
BEST SURGE PROTECTION
PERFORMANCE LEVEL UP
FLEXIBLE COOLING CONTROLS
GPU TEMPERATURE SENSING
System temperatures are key to a stable gaming rig ― especially GPU temperatures. TUF Gaming motherboards include Fan Xpert 4 Core software that's able to intelligently control system fans based upon the input of multiple sensors, including the temperature of ASUS graphics cards*. This ensures that your TUF Gaming system stays perfectly cooled, no matter how long you play.
* ASUS GeForce 700 and later cards supported.
FAN XPERT 4 CORE
TUF B450-PLUS Gaming features the most comprehensive fan controls ever, configurable via Fan Xpert 4 Core and our award-winning UEFI BIOS.
General Information
| UPC | 192876075944 |
|---|
