Overview:
The APC Smart-UPS RT 20kVA is a high-performance, rackmountable power protection solution designed for critical data center and IT infrastructure equipment. With on-line double-conversion technology, it provides robust power backup and conditioning to ensure equipment safety and stability.
Key Features:
-
20kVA/16kW power capacity to support large IT clusters and data center equipment
-
Double-conversion on-line technology offering seamless power management and conditioning
-
LCD Display for easy status updates and system monitoring
-
Rackmount design to fit neatly into standard 14U rack space
-
17 NEMA outlets including 12x 5-20R and 4x L6-20R ensuring versatile connectivity for critical equipment
-
Transformer module converts voltage from 208V to 120V to accommodate various power needs
Technical Specifications:
| Manufacturer |
APC by Schneider Electric |
| Model Number |
SURT20KRMXLT-TF5 |
| Power Capacity |
20kVA/16kW |
| Input Voltage |
208V |
| Output Connections |
12x 5-20R, 4x L6-20R, 1x L6-30R |
| Form Factor |
Rackmount (14U) |
| Technology |
Double-conversion on-line |
| Display |
LCD |
Frequently Asked Questions:
Q: What is the benefit of double-conversion on-line technology in this UPS?
A: Double-conversion on-line technology provides the highest level of protection against power disturbances by converting incoming AC power to DC and then back to clean AC power, ensuring constant voltage and frequency regulation.
Q: How does the transformer feature benefit installation?
A: The transformer allows for voltage conversion from 208V to 120V, enabling compatibility with a wide array of devices and installations that require different voltage levels.
Q: Can this UPS support a large data center environment?
A: Yes, with its 20kVA capacity and multiple NEMA outlets, this UPS is well-equipped for supporting large-scale environments, ensuring consistent uptime for mission-critical systems.
