APC SMX2000RMLV2U. Output power capacity: 1.92 kVA, Output power: 1800 W, Input operation voltage (min): 75 V. AC outlet types: NEMA 5–15R,NEMA 5–20R, AC outlets quantity: 7 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Width: 432 mm, Depth: 667 mm, Height: 85 mm
Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
High frequency design Reduces or eliminates bulky transformers resulting in lighter units for ease of handling.
Auto recognition of external batteries UPS recognizes when external battery packs are attached and automatically adjusts runtime.
Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Energy meter Provides actual kilowatt hours of usage for energy conscious users.
Outlet group control Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups).
Sequenced shutdown and restart Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups).
Load shedding Turn off select outlet groups in a pre-determined sequence to shed less critical equipment and conserve runtime (UPSs with switched outlet groups).
InfraStruXure Central compatible Enables centralized management via APC InfraStruXure® Central.
Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Multiple switched outlet groups Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
Wide input voltage range Designed for harsh electrical environments to save battery life.
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SMX2000RMLV2U
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Line
Smart-UPS
Product Series
X
Product Model
SMX2000RMLV2U
Product Name
Smart-UPS X SMX2000RMLV2U 1920 VA Rack-mountable UPS
Product Type
Line-interactive UPS
UPC
731304268536
Battery Information
Battery Chemistry
Lead Acid
Product Color
Black
Height
3.3"
Width
17"
Depth
26.3"
Weight (Approximate)
84.77 lb
Miscellaneous
Package Contents
Smart-UPS X SMX2000RMLV2U 1920 VA Rack-mountable UPS
CD with software
Documentation CD
Installation guide
Rack mounting brackets
Rack mounting hardware
Rack mounting support rails
Removable support feet
Smart UPS signalling RS-232 cable
USB cable
Environmentally Friendly
Yes
Environmental Certification
RoHS
Warranty
Limited Warranty
3 Year
Additional Warranty Information
3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available
