This APC Smart-UPS VT 10kVA is perfect for enterprise data centers and mission-critical facilities who need reliable server rack battery backup protection. Our solution delivers:
-
Enterprise-grade power protection for critical server infrastructure
-
Rack mount design for efficient data center deployment
-
Parallel capability for scalable redundancy and increased capacity
-
Maintenance bypass operation for zero-downtime servicing
Key Features
-
10kVA/10kW output capacity to support high-density server loads
-
400V three-phase input/output for enterprise power distribution
- Optimized for rack mount installation with 6U form factor
- Consistent online double-conversion topology for maximum protection
-
Hot-swappable battery modules for extended runtime flexibility
-
Internal maintenance bypass for uninterrupted power during service
-
Parallel redundancy capability up to 4 units for N+1 protection
-
Network management interface for remote monitoring and control
Technical Specifications
| Manufacturer |
Schneider Electric (APC) |
| Model Number |
SUVTP10KH2B4S |
| Type |
Enterprise Rack Mount UPS |
| Power Rating |
10kVA / 10kW |
| Input Voltage |
400V 3-phase + neutral |
| Output Voltage |
400V 3-phase + neutral |
| Form Factor |
6U 19-inch rack mountable |
| Topology |
Online Double Conversion |
| Battery Configuration |
2 battery modules, expandable to 4 |
| Runtime |
10 minutes at full load (2 battery modules) |
| Bypass Type |
Internal maintenance bypass |
| Parallel Capability |
Up to 4 units for redundancy/capacity |
| Network Interface |
SmartSlot for network management cards |
| Display |
LCD status display with alarm indicators |
| Compatible Systems |
Enterprise servers, storage arrays, network equipment |
Frequently Asked Questions
Q: What is the runtime of this APC Smart-UPS VT 10kVA system?
A: With the standard 2 battery modules, it provides approximately 10 minutes runtime at full 10kW load. Runtime can be extended by adding up to 2 additional battery modules for maximum flexibility.
Q: Can this UPS be configured for parallel operation?
A: Yes, it's engineered for parallel redundancy capability supporting up to 4 units. This enables both N+1 redundancy for high availability and increased power capacity for growing loads.
Q: Does this support hot-swappable maintenance?
A: Absolutely. The internal maintenance bypass allows for zero-downtime servicing — perfect for mission-critical environments that cannot afford power interruptions during maintenance.
Q: Is this UPS suitable for data center rack mounting?
A: Yes. This 6U rack mount design fits standard 19-inch server racks with front-access serviceability, making it ideal for high-density data center deployments with efficient space utilization.
APC Smart-UPS VT 10kVA for enterprise data centers. Rack mount design with parallel capability and maintenance bypass for mission-critical power protection.
