APC Maintenance Bypass Panel GVSBPSU150KH - 150kW 400V Wall-Mount Solution
The GVSBPSU150KH maintenance bypass panel is engineered for organizations requiring seamless UPS service operations without power interruption. This 150kW 400V wall-mounted bypass panel is specifically designed for Galaxy VS and Easy UPS 3M installations, enabling complete UPS isolation during maintenance while maintaining continuous power delivery to critical infrastructure. Perfect for data centers, enterprise facilities, and mission-critical environments where downtime equals lost revenue, this single-unit solution ensures your systems stay online during planned service intervals.
Key Features
- Single-unit maintenance bypass panel design for simplified installation and operation
- 150kW capacity rated for 400V three-phase applications
- Wall-mounted configuration optimizes space utilization in equipment rooms
- Compatible with Galaxy VS and Easy UPS 3M UPS systems
- Enables complete UPS isolation during maintenance and service operations
- Maintains power continuity to connected loads during bypass mode
- Integrated into APC by Schneider Electric's critical power accessory portfolio
- Supports enterprise-grade reliability and uptime requirements
Technical Specifications
| Specification |
Details |
| Manufacturer |
APC by Schneider Electric |
| Part Number |
GVSBPSU150KH |
| Product Type |
Maintenance Bypass Panel |
| Power Rating |
150 kW |
| Voltage |
400V (Three-Phase) |
| Installation Type |
Wall-Mount |
| Configuration |
Single Unit |
| Compatible Systems |
Galaxy VS, Easy UPS 3M |
| Primary Function |
UPS Isolation & Maintenance Bypass |
Frequently Asked Questions
What is a maintenance bypass panel used for?
A maintenance bypass panel allows you to isolate your UPS system for service and maintenance while keeping power flowing to your critical equipment. The GVSBPSU150KH enables technicians to perform repairs, replacements, or upgrades without shutting down connected systems.
Is the GVSBPSU150KH compatible with my UPS system?
The GVSBPSU150KH is specifically designed for Galaxy VS and Easy UPS 3M series UPS systems from APC by Schneider Electric. Verify your UPS model matches these ranges before installation. Contact our technical team for compatibility confirmation with your specific setup.
How does wall-mount installation benefit my data center?
Wall-mounting the 150kW bypass panel saves valuable floor space in equipment rooms and data centers while maintaining easy access for maintenance operations. This configuration is ideal for facilities with space constraints or standardized rack-based infrastructure layouts.
Can this bypass panel handle 400V three-phase power?
Yes, the GVSBPSU150KH is rated for 400V three-phase applications at 150kW capacity, making it suitable for enterprise and industrial installations requiring high-power UPS protection and maintenance capabilities.
