APC Isolation Transformer. Output current: 100 A, Certification: C-tick, CE, CSA, EN 55022 Class A, EN 55024, EN 60950, EN 61000-3-2, EN 61000-3-3, GOST, UL.... Product colour: Black. Weight: 118.2 kg. Dimensions (WxDxH): 432 x 757 x 175 mm, I/O ports: 2 x (2PH + G) 1 x (H N + G) 2 x (2PH + N +G) 1 x (1PH+N+G)
Rack-Mountable Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Transformer for Step-down or Step-up or Isolation Step down transformer placed upstream of the UPS to avoid inrush current and saturation eliminating need to oversize transformer.
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
APTF20KW01
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Name
20kVA Isolation Rack-mountable Transformer
Product Type
Isolation Transformer
UPC
731304242222
Height
6.9"
Width
17"
Depth
29.8"
Weight (Approximate)
260.54 lb
Miscellaneous
Package Contents
20kVA Isolation Rack-mountable Transformer
Documentation CD
Hardwire panel
Installation guide
Rack mounting brackets
User manual
Environmentally Friendly
Yes
Environmental Certification
RoHS
Warranty
Limited Warranty
2 Year
Additional Warranty Information
2 years repair or replace
