APC Galaxy VS Parallel Maintenance Bypass Panel for Dual UPS Systems
The Galaxy VS Parallel Maintenance Bypass Panel (GVSBPAR10K30H) is engineered for organizations requiring uninterrupted power during UPS maintenance. Designed for two Galaxy VS UPS systems in the 10–30 kW range at 400V, this wall-mounted bypass solution enables safe isolation and servicing of critical power equipment without interrupting load power delivery. Ideal for data centers, server rooms, and mission-critical facilities where downtime is not an option, this parallel maintenance bypass panel ensures continuous operation while your UPS units receive essential maintenance and support.
Key Features
- Dual UPS parallel configuration support for 10–30 kW systems
- 400V three-phase input and output compatibility
- Wall-mounted design for space-efficient installation
- Safe isolation capability for individual UPS maintenance
- Maintains load power during service operations
- Part of the APC Galaxy VS ecosystem for seamless integration
- Engineered for critical power environments and high availability
- Reliable parallel switching for redundant power delivery
Technical Specifications
| Specification |
Details |
| Manufacturer |
APC by Schneider Electric |
| Part Number |
GVSBPAR10K30H |
| Product Type |
Parallel Maintenance Bypass Panel |
| Compatible UPS Range |
10–30 kW |
| Input/Output Voltage |
400V, three-phase |
| Mounting Type |
Wall-mounted |
| Application |
Dual Galaxy VS UPS systems |
| Primary Function |
Safe UPS isolation and maintenance bypass |
Frequently Asked Questions
What is a parallel maintenance bypass panel used for?
A parallel maintenance bypass panel allows you to safely isolate one or both UPS units for maintenance, repair, or replacement while the connected load remains powered through the bypass path. This eliminates costly downtime in critical power environments.
Can this bypass panel work with a single UPS system?
The GVSBPAR10K30H is specifically designed for two Galaxy VS UPS systems operating in parallel. For single UPS configurations, alternative bypass solutions may be more appropriate.
What power range does this maintenance bypass panel support?
This panel supports dual Galaxy VS UPS systems in the 10–30 kW power range at 400V, making it suitable for mid-sized data centers and critical infrastructure applications.
How does the wall-mounted design benefit installation?
The wall-mounted configuration saves valuable floor space in server rooms and data centers while maintaining easy access for monitoring and maintenance operations on the bypass panel itself.
