This switched power distribution unit is perfect for data center administrators and IT professionals who need intelligent power distribution unit capabilities with remote control. Our solution delivers:
-
Network managed PDU functionality that provides complete remote monitoring and control
-
ZeroU rack mount power distribution unit design for optimal space utilization
-
Server power distribution unit compatibility ensuring seamless integration
-
High temperature power management for demanding environments up to 60°C
Key Features
-
Remote power monitoring and control via embedded APC Network Management Card 3
-
6.2kW maximum power capacity for high-density server environments
- Optimized for ZeroU mounting configuration to maximize rack space efficiency
- Consistent high temperature performance up to 60°C for reliable operation
-
Multi-outlet compatibility including NEMA 5-20R, C13/C15, and C19 connections
Technical Specifications
| Manufacturer |
APC by Schneider Electric |
| Model Number |
APDU9970 |
| Type |
Switched Rack Power Distribution Unit |
| Power Capacity |
6.2kW Maximum |
| Input |
30A, 120/208V |
| Outlets |
16 NEMA 5-20R, 7 C13/C15, 1 C19/C21 |
| Network Management |
APC Network Management Card 3 (NMC) |
| Operating Temperature |
Up to 60°C |
| Mounting |
ZeroU Rack Mount Design |
| Compatible Systems |
Server racks, data center infrastructure, enterprise networks |
Frequently Asked Questions
Q: What makes this different from a standard rack power distribution unit?
A: This intelligent power distribution unit provides advanced network management capabilities, allowing remote monitoring and individual outlet control through the embedded APC Network Management Card 3.
Q: Can this switched power distribution unit handle high-density server environments?
A: Yes, it's engineered for enterprise data center power management with 6.2kW capacity and high temperature performance up to 60°C, perfect for demanding server deployments.
Q: How does the ZeroU design benefit my rack configuration?
A: The ZeroU rack mount power distribution unit design saves valuable rack space by mounting vertically in the rack, maximizing available space for servers and networking equipment.
Q: Is this compatible with existing network monitoring systems?
A: Yes. The embedded network managed PDU capabilities integrate seamlessly with SNMP-based monitoring systems and APC's PowerChute software for comprehensive power management.
Switched power distribution unit for data centers. 6.2kW intelligent PDU with ZeroU design and network management for enterprise server racks.
