Altronix AL1024ULXPD8 Proprietary Power Supply
Model AL1024ULXPD8 power supply/charger converts a 115VAC 60Hz input, to 24VDC @ 10 amp supply current for Access Control application, 24VDC @ 8 amp supply current with 10 amp during alarm for Fire Alarm applications distributed via eight (8) fuse protected non power limited outputs. Model AL1024ULXPD8CB is a PTC protected version of this unit.
- UL and cUL listed.
- AC and battery monitoring.
- 24VDC @ 10A, fused non-power limited outputs.
- 8 Output Power Supply/Charger.
Product Type: Proprietary Power Supply
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: United States
Brand Name: Altronix
Compatibility:
- Access Control Systems
- Fire Protective Signaling Systems
Form Factor: Enclosure
Manufacturer: Altronix Corporation
Product Model: AL1024ULXPD8
Product Name: AL1024ULXPD8 Proprietary Power Supply
Manufacturer Part Number: AL1024ULXPD8
Manufacturer Website Address: http://www.altronix.com
Packaged Quantity: 1
Limited Warranty: Lifetime
Weight (Approximate): 10.40 lb
