Altronix AL1024ULXPD16CB Proprietary Power Supply
Model AL1024ULXPD16CB power supply/charger converts a 115VAC 60Hz input, to 24VDC @ 10 amp supply current for Access Control application, 24VDC @ 8 amp supply current with 10 amp during alarm for Fire Alarm applications distributed via sixteen (16) PTC protected Class 2 Rated outputs. Model AL1024ULXPD16 is a fuse protected version of this unit.
- 24VDC @ 10A, PTC Class 2 power-limited outputs.
- AC and battery monitoring.
- UL and cUL listed.
- 16 Output Power Supply/Charger.
Product Type: Proprietary Power Supply
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: United States
Brand Name: Altronix
Compatibility:
- Access Control Systems
- Fire Protective Signaling Systems
Form Factor: Wall Mount
Manufacturer: Altronix Corporation
Product Model: AL1024ULXPD16CB
Product Name: AL1024ULXPD16CB Proprietary Power Supply
Manufacturer Part Number: AL1024ULXPD16CB
Manufacturer Website Address: http://www.altronix.com
Packaged Quantity: 1
Limited Warranty: Lifetime
Weight (Approximate): 11.30 lb
