Advantech IE-Multiway IMC-574I Transceiver/Media Converter
Introduction
The IMC-574I is a value-based, managed Gigabit Ethernet solution that is ideal for use in fiber infrastructure. The IMC-574I comes with two SFP ports and two fixed 10/100/1000Base-T copper ports. There are four distinct DIP switch selectable configurations that feature the IMC-574I to be a 1+1 uplink port revertive mode, a 1+1 uplink protection non-revertive mode, a 4-port Gigabit switch, and a dual copper-to-fiber SFP media/mode converter (two Gigabit fiber media converters in one).
The term "1+1" refers to line protection where identical information is transmitted on two lines. The receiver chooses its communication line based on the revertive or non-revertive configuration. When a fault is detected on the active line, the traffic is switched to the redundant line. In the non-revertive mode, data is not resumed back to the original line unless the backup line fails or is disconnected. Once the original line is no longer in a fault condition, data can be resumed back to the original line.
- Supports OAM, VLAN, 1+1 revertive
- Provides RS-232 CLI (command line interface) console port
- Works under an extended temperature range
- Supports SNMP for management
- Supports a variety of SFP modules
- Versatile 4-port media converter
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: Taiwan
Brand Name: Advantech
Form Factor: DIN Rail Mountable
Manufacturer: Advantech Co., Ltd
Product Model: IMC-574I
Product Name: IE-Multiway IMC-574I Transceiver/Media Converter
Product Line: IE-Multiway
Manufacturer Part Number: IMC-574I-SFP-PS-A
Manufacturer Website Address: http://www.advantech.com
Weight (Approximate): 15.87 oz
