This mini media converter is perfect for space-constrained environments, small offices, and network installations requiring compact ethernet to fiber converter solutions. Our AddOn Networks ADD-FMCMN-FX-SC delivers:
-
10/100Base-TX to 100Base-FX conversion that enables seamless copper to fiber transitions in small form factor
-
Multimode fiber converter functionality supporting 2km distance over MMF 1310nm wavelength
-
Compact design ideal for desktop installations and space-limited network environments
-
Cost-effective network expansion perfect for small business and remote office connectivity
Key Features
-
Converts 10/100Base-TX to 100Base-FX enabling copper ethernet to fiber optic transitions
-
SC connector compatibility with multimode fiber supporting 1310nm wavelength
- Optimized for small form factor installations with compact desktop design
- Consistent fast ethernet performance maintaining 100 Mbps data transmission speeds
-
Plug-and-play operation requiring minimal configuration for quick deployment
- Compatible with fiber ethernet switches and standard network equipment
Technical Specifications
| Manufacturer |
AddOn Networks |
| Model Number |
ADD-FMCMN-FX-SC |
| Type |
Mini Media Converter |
| Conversion Type |
10/100Base-TX to 100Base-FX |
| Copper Port |
1 x RJ-45 10/100Base-TX |
| Fiber Port |
1 x SC connector |
| Fiber Type |
Multimode Fiber (MMF) |
| Wavelength |
1310nm |
| Maximum Distance |
Up to 2 kilometers |
| Data Rate |
10/100 Mbps auto-sensing |
| Form Factor |
Compact mini desktop unit |
| Power Supply |
External power adapter |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| LED Indicators |
Power, Link, Activity status |
| Dimensions |
Compact mini form factor |
| Standards Compliance |
IEEE 802.3, 802.3u standards |
Frequently Asked Questions
Q: What is the primary advantage of this mini media converter?
A: This mini converter provides space-efficient 10/100Base-TX to fiber conversion in a compact form factor, perfect for desktop installations and small office environments where space is at a premium.
Q: What type of fiber does this converter support?
A: It supports multimode fiber (MMF) with 1310nm wavelength, enabling connections up to 2 kilometers distance with SC connectors for secure fiber optic connectivity.
Q: How does this benefit small network installations?
A: This ethernet to fiber converter enables cost-effective network extension beyond copper limitations while maintaining a small footprint, ideal for connecting remote buildings or extending network reach in space-constrained environments.
Q: What data rates does this mini converter support?
A: The converter supports 100Base-FX fiber connections with auto-sensing 10/100 Mbps ethernet speeds, automatically detecting and configuring for optimal performance based on connected equipment.
Q: Is this suitable for desktop installations?
A: Yes, the network media converter features a compact mini design perfect for desktop use, with external power supply and LED status indicators for easy monitoring and plug-and-play operation.
Mini media converter 10/100Base-TX to 100Base-FX SC, MMF 1310nm, 2km. AddOn Networks compact ethernet to fiber converter for small office network installations.
