ADD-GMC-MMSM-2SC Media Converter
The ADD-GMC-MMSM-2SC is a versatile media converter from AddOn Networks, engineered for converting 1000Base-SX (short-range multimode fiber) to 1000Base-LX (long-range single-mode fiber). This functionality is essential in bridging networks over different fiber types and extending connections up to 20 kilometers.
Target Use Cases
- Network engineers and IT professionals looking to extend their LAN over long distances.
- Data centers requiring seamless integration between multimode and single-mode fibers.
Features & Benefits
-
Dual wavelength support: Operates over 850nm and 1310nm for various fiber optic applications.
-
SC connectivity: Uses SC connectors for reliable connections across both multimode and single-mode setups.
-
Extended distance: Supports 550 meters for multimode and up to 20 kilometers for single mode.
-
Auto-negotiation: Facilitates smooth integration with existing infrastructure.
Technical Specifications
| Manufacturer |
AddOn Networks |
| Model Number |
ADD-GMC-MMSM-2SC |
| Type |
MMF to SMF Media Converter |
| Interfaces |
1000Base-SX (850nm) to 1000Base-LX (1310nm) |
| Data Rate |
1 Gbps |
| Connectors |
SC Duplex |
| Power Consumption |
<5W |
| Operating Temperature |
0°C to 50°C |
Frequently Asked Questions
Q: Can the ADD-GMC-MMSM-2SC support existing fiber installations?
A: Yes, it uses standard SC connectors compatible with existing infrastructure.
Q: What maximum distance does it support?
A: It supports 550m on multimode fiber and up to 20km on single-mode fiber.
Q: Is it suitable for enterprise use?
A: Absolutely, it's ideal for enterprises needing to bridge different fiber types across long distances.
Q: Does it require additional power supply?
A: Yes, the converter includes an external power adapter and has a power consumption of less than 5 Watts.
