This AO-GES-42-S unmanaged switch is perfect for small businesses, home offices, and network administrators requiring simple gigabit ethernet switch connectivity. Our reliable network switch solution delivers:
-
Plug-and-play simplicity with zero configuration required for immediate deployment
-
Gigabit ethernet performance ensuring high-speed data transfer across all ports
-
Cost-effective networking providing enterprise-grade connectivity without management complexity
-
Reliable uptime with robust design for 24/7 operation in business environments
Key Features
-
Auto-negotiation technology automatically detecting optimal speed and duplex settings
-
Store-and-forward switching ensuring error-free packet transmission
-
LED status indicators providing real-time port activity monitoring
-
Fanless design enabling silent operation in office environments
-
Auto-MDI/MDIX support eliminating the need for crossover cables
-
Jumbo frame support optimizing large file transfers and network efficiency
Technical Specifications
| Manufacturer |
AddOn |
| Model Number |
AO-GES-42-S |
| Type |
Unmanaged Gigabit Ethernet Switch |
| Port Configuration |
4 x 10/100/1000 Base-T RJ45 ports, 2 x SFP ports |
| Switching Capacity |
84 Gbps wire-speed non-blocking |
| Forwarding Rate |
62.5 Mpps (million packets per second) |
| MAC Address Table |
16,000 MAC address entries |
| Buffer Memory |
4.1 MB packet buffer |
| Jumbo Frame Support |
Up to 9,216 bytes |
| Power Consumption |
Maximum 45W |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Form Factor |
19-inch rack mountable, 1U height |
| Certifications |
FCC, CE, UL, RoHS compliant |
| Target Applications |
Small Business, Office Networks, Workgroup Connectivity |
| Compatible Devices |
Computers, Servers, Printers, IP Phones, Access Points |
Frequently Asked Questions
Q: What makes this switch ideal for small business networks?
A: The AO-GES-42-S unmanaged switch provides plug-and-play simplicity with no configuration required, making it perfect for businesses that need reliable gigabit ethernet switch performance without the complexity of managed switches or dedicated IT staff.
Q: How many devices can I connect to this switch?
A: This switch supports connection of up to 6 devices (4 RJ-45 and 2 SFP), each running at high-speed gigabit rates, ideal for small to medium-sized offices.
Q: Does this switch require any special cables or configuration?
A: No, this switch features auto-MDI/MDIX on all ports, eliminating the need for crossover cables. Simply connect standard Ethernet cables and the switch automatically detects and configures optimal settings for each connected device.
Q: Can this switch handle high-bandwidth applications?
A: Yes, with 84 Gbps switching capacity and jumbo frame support up to 9,216 bytes, this switch efficiently handles bandwidth-intensive applications like video streaming, large file transfers, and database operations across your network.
AO-GES-42-S unmanaged gigabit ethernet switch with 42 ports providing plug-and-play networking for small business and office environments.
