15m ST to LC Orange OM2 Duplex OFNR Fiber Patch Cable
The ADD-ON 15m ST to LC Orange OM2 Duplex OFNR (Riser-Rated) fiber patch cable is engineered for high-performance network installations requiring reliable multimode connectivity. This ST to LC fiber optic cable delivers 50/125µm core specifications ideal for data centers, telecommunications facilities, and enterprise network infrastructure. The OFNR riser-rated design ensures safe installation in building plenum spaces while maintaining optimal signal integrity across 15-meter distances. Perfect for network administrators and IT professionals upgrading legacy ST-based systems to modern LC connector standards.
Key Features
- 15-meter length ST to LC connector configuration for seamless system integration
- OM2 multimode fiber (50/125µm) supporting up to 2 Gbps over extended distances
- Duplex design enables simultaneous bidirectional data transmission
-
OFNR riser-rated construction meets building fire safety codes
- Orange jacket for easy identification and cable management
- Precision-polished connectors minimize insertion loss and return loss
- Durable PVC outer jacket resists environmental degradation
- Compatible with existing ST and LC infrastructure
Technical Specifications
| Specification |
Details |
| Manufacturer |
ADD-ON |
| Part Number |
ADD-ST-LC-15M5OM2 |
| Cable Length |
15 meters |
| Connector Type A |
ST (Straight Tip) |
| Connector Type B |
LC (Lucent Connector) |
| Fiber Type |
OM2 Multimode (50/125µm) |
| Configuration |
Duplex |
| Jacket Rating |
OFNR (Riser-Rated) |
| Jacket Color |
Orange |
| Maximum Bandwidth |
2 Gbps (OM2 standard) |
| Insertion Loss |
<0.3 dB per connector |
| Operating Temperature |
-10°C to +60°C |
Frequently Asked Questions
What is the difference between ST and LC fiber connectors?
ST connectors use a bayonet-style coupling mechanism and are common in legacy installations, while LC connectors feature a push-pull design and smaller form factor. The ST to LC fiber patch cable bridges these two standards, allowing seamless connectivity between older ST-based equipment and modern LC infrastructure without requiring expensive equipment replacement.
Is this OFNR riser-rated cable suitable for plenum installations?
OFNR (Optical Fiber Non-Conductive Riser) rating means this cable is approved for use in building riser spaces between floors. However, for true plenum spaces (air handling areas), you would need OFNP-rated cable. The OFNR riser-rated design ensures compliance with fire safety codes for standard vertical cable runs in commercial buildings.
Can I use OM2 multimode fiber for long-distance connections?
OM2 multimode fiber supports distances up to 2 km at 1 Gbps and shorter distances at higher speeds. For this 15-meter patch cable, OM2 provides excellent performance with minimal signal degradation. If you require longer distances or higher speeds, consider upgrading to OM3 or OM4 multimode, or single-mode fiber for enterprise backbone applications.
What makes this fiber optic cable suitable for data center environments?
Data centers require reliable, high-performance connectivity with proper fire safety ratings. This ST to LC multimode fiber cable combines OM2 specifications for robust 2 Gbps performance, OFNR fire-rated construction for safety compliance, and precision connectors that minimize signal loss—making it ideal for connecting network switches, storage systems, and server infrastructure.
