The Vertiv Avocent AV 3108 KVM over IP Switch is perfect for IT administrators, data center operators, and system engineers who need secure remote server management with advanced virtual media capabilities and CAC authentication. Our solution delivers:
-
KVM over IP technology that enables remote server access from anywhere on the network
-
Server management capabilities with comprehensive remote control and monitoring
-
Virtual media support for remote OS installation, patching, and troubleshooting
-
CAC authentication ensuring military-grade security for government and enterprise environments
Key Features
-
8-port KVM connectivity to manage multiple servers from single console
-
Remote access capabilities via web browser or dedicated client software
-
Virtual media functionality supporting CD/DVD, USB, and floppy emulation
-
CAC smart card support for secure multi-factor authentication
-
High-resolution video support up to 1920x1200 at 60Hz
-
SSL encryption protecting all data transmissions
-
Multi-user access with granular permission controls
-
BIOS-level access for complete server control including boot sequences
Technical Specifications
| Manufacturer |
Vertiv |
| Model Number |
AV 3108 |
| Type |
8-Port KVM over IP Switch |
| Port Configuration |
8 x Server ports (VGA + USB/PS2) |
| Network Interface |
10/100/1000 Ethernet (RJ45) |
| Local Console Ports |
VGA, USB, PS/2 keyboard/mouse |
| Video Resolution |
Up to 1920x1200 @ 60Hz |
| Color Depth |
24-bit true color |
| Virtual Media |
CD/DVD, USB drives, floppy disk emulation |
| Authentication Methods |
Local users, LDAP, Active Directory, RADIUS, CAC |
| CAC Support |
Common Access Card smart card authentication |
| Encryption |
128-bit SSL, SSH, HTTPS |
| Maximum Users |
4 simultaneous remote users |
| Browser Support |
Internet Explorer, Firefox, Chrome, Safari |
| Client Software |
Windows, Linux, Mac OS X viewers |
| Power Consumption |
45W maximum |
| Power Supply |
External 100-240V AC adapter |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Humidity |
80% non-condensing |
| Dimensions |
17.2" x 8.1" x 1.7" (437 x 206 x 44 mm) |
| Weight |
6.6 lbs (3.0 kg) |
| Mounting |
1U rack-mount with included brackets |
| MTBF |
150,000 hours at 25°C |
| Compliance |
FCC Class A, CE, UL, cUL, VCCI |
| Standards |
IEEE 802.3, TCP/IP, HTTP, HTTPS, SSL, SSH |
| Compatible Systems |
Windows, Linux, Unix servers, blade servers, network appliances, data center equipment |
Frequently Asked Questions
Q: What makes KVM over IP technology essential for modern data centers?
A: The Vertiv Avocent AV 3108 KVM over IP switch enables remote server management from any location with network access, eliminating the need for physical presence in the data center. This dramatically reduces operational costs, improves response times for critical issues, and enables 24/7 monitoring without on-site staff.
Q: How does virtual media support enhance server management capabilities?
A: Virtual media functionality allows you to remotely mount CD/DVDs, USB drives, and floppy images directly to target servers. This enables remote OS installation, BIOS updates, software patching, and disaster recovery operations without physical access to the server hardware, significantly reducing maintenance time and travel costs.
Q: What CAC authentication capabilities does this switch provide?
A: The switch supports Common Access Card (CAC) smart card authentication, meeting Department of Defense and government security requirements. CAC support provides multi-factor authentication combining smart card credentials with PIN verification, ensuring only authorized personnel can access critical server infrastructure.
Q: How many users can simultaneously access the remote servers?
A: The AV 3108 KVM over IP switch supports up to 4 simultaneous remote users with granular permission controls. Each user can have different access levels, from view-only to full control, enabling collaborative troubleshooting while maintaining security boundaries for different administrative roles.
Q: What video quality can I expect for remote server management?
A: The switch supports high-resolution video up to 1920x1200 at 60Hz with 24-bit true color depth. This provides crisp, clear video quality essential for detailed server configuration, monitoring complex graphical interfaces, and accurate troubleshooting of server applications and operating systems.
Q: How secure are the remote connections for sensitive environments?
A: All communications are protected with 128-bit SSL encryption, SSH, and HTTPS protocols. Combined with multiple authentication methods including LDAP, Active Directory, RADIUS, and CAC support, the switch provides enterprise-grade security suitable for government, military, and highly regulated commercial environments.
Q: Can this KVM switch integrate with existing network management systems?
A: Yes, the switch supports standard network protocols and can integrate with existing IT infrastructure. It provides SNMP support for network monitoring, syslog for centralized logging, and can authenticate against existing Active Directory or LDAP systems, ensuring seamless integration with current IT management practices.
Vertiv Avocent AV 3108 KVM over IP Switch providing 8-port remote server management with virtual media, CAC authentication, and secure remote access capabilities.
