Allied Telesis GS950/10PS V2 Ethernet Switch
The Allied Telesis GS950/10PS V2 Gigabit PoE+ WebSmart switch features 8 x 10/100/1000T ports and two SFP ports, delivering up to 30 Watts per port (PoE+) to support video surveillance cameras, wireless access points, IP phones and other powered devices. PoE+ eliminates the need for separate power cabling and minimizes the clutter of power supplies and adapters for simplified deployment. Thanks to its compact size, the AT-GS950/10PS V2 is ideal for wiring-constrained and smaller environments such as micro branch offices, classrooms, cafes, and smaller retail stores.
- VLAN: IEEE 802.1Q tagged - Port-based - Up to 256 groups
- Quality of Service Classification: IEEE 802.1p tagging - Port-based priority - Four priority queues per port
- IP Multicast Support (IPv4) - IGMP snooping (v1/v2) - Static multicast group (up to 256) - Spanning-Tree, IEEE 802.1d/w/s
- IEEE 802.3ad Link Aggregation: Manual - LACP
- IEEE 802.1x Port-based, MAC-based and Network Access Control: Local authentication server (MD5 only) - Remote authentication through RADIUS - Dynamic VLAN assignment - RADIUS Client
- Other: IEEE 802.3x flow control or HOL blocking prevention ( when flow control is off) - Port mirroring - Destination MAC filtering - Ingress/egress rate limiting - Broadcast storming control - 100 FX SFP support - Jumbo Frames - up to 10K
- Management Features: SSH - Telnet - Web-based configuration - CLI configuration - SNMP trap view - LLDP - Firmware upgrade by FTP and HTTP - Configuration backup/restore by FTP and HTTP - Factory reset - Password access control and restricted - IP access list - SNMPv1/v2c/v3 - DHCP client - Syslog support - System time configuration (SNTP, manual) - Statistics Charts in Web
- MIBs : RFC 1213 MIB-II - RFC 1643 Ethernet MIB - RFC 1493 Bridge MIB - RFC 2131 DHCP client - Private Enterprise MIB (Allied Telesis provides the spec)
- RMON Groups (1, 2, 3, 9): Stats - History - Alarms - Events
- ACL: Support (number of entries 188)
Product Type: Ethernet Switch
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Series: GS950 V2
Brand Name: Allied Telesis
Form Factor: Desktop
Manufacturer: Allied Telesis, Inc
Product Model: GS950/10PS V2
Product Name: GS950/10PS V2 Ethernet Switch
Manufacturer Part Number: AT-GS950/10PS V2-10
Manufacturer Website Address: http://www.alliedtelesis.com
Package Contents:
- GS950/10PS V2 Ethernet Switch
- Rack-mount Brackets and Screws
- US Power Cord
- Rubber Feet
Weight (Approximate): 4.19 lb
