The HANWHA VISION 8K NVR (Intel-based) is a high-performance network video recorder built for professional security deployments that demand ultra-high-definition recording and rock-solid reliability. Designed for enterprise networks, it supports up to 32 channels and integrates seamlessly with HANWHA VISION’s AI capabilities and broad third-party compatibility.
-
Channels: 32-channel surveillance support for large camera deployments
-
Storage: 10TB RAW with 8 SATA HDD bays, supporting up to 10TB per HDD
-
Video compression: Supports H.265, H.264, and MJPEG for efficient storage and broad compatibility
-
Recording bandwidth: Max 520 Mbps recording bandwidth for high-frame-rate capture
-
Playback bandwidth: Up to 200 Mbps playback bandwidth for smooth review
-
Display outputs: 2x HDMI outputs for dual-display monitoring
-
Audio: 2-way audio support for bidirectional sound capture
-
Advanced reliability: ARB (Automatic Recovery Backup) and Failover (N+1) to minimize downtime
-
AI and image tools: AI Search for Wisenet AI cameras; Fisheye Dewarping for wide-angle lenses
-
Connectivity and integration: SUNAPI, ONVIF, iSCSI, and WiseStream support for flexible integration
-
Resolution support: Ultra-high-definition recording up to 32MP with compatible cameras
This NVR excels in demanding environments by pairing expansive storage with intelligent features and robust failover. Dual HDMI outputs empower operators with simultaneous live monitoring and detailed review, while ARB and N+1 failover preserve recording continuity even during component failures. AI search capabilities speed up incident response when paired with Wisenet AI cameras, and Fisheye dewarping delivers clear, navigable views for panoramic lenses.
Specifications
-
Channels: 32
-
Storage: 10TB RAW with 8 SATA bays (up to 10TB per HDD)
-
Max Recording Bandwidth: 520 Mbps
-
Max Playback Bandwidth: 200 Mbps
-
Video Compression: H.265, H.264, MJPEG
-
Display Outputs: 2x HDMI
-
Audio: 2-way
-
Special Features: ARB, Failover (N+1), AI Search, Fisheye Dewarping
-
AI and Compatibility: AI Search for Wisenet AI cameras; SUNAPI, ONVIF, iSCSI, WiseStream
-
Resolution Support: Up to 32MP recording with compatible cameras
Frequently Asked Questions
-
What is the maximum camera resolution supported? – Up to 32MP for compatible cameras.
-
Can the NVR handle failover automatically? – Yes, it supports automatic N+1 failover to maintain recording during component failures.
-
What video formats does it support? – H.265, H.264, and MJPEG for flexible bandwidth and storage management.
-
Does it support dual display? – Yes, via two HDMI outputs for separate monitoring rooms or operator desks.
-
Is AI search available for all cameras? – AI search is available for Wisenet AI cameras; non-AI cameras will not populate AI search results.
