ComNet VBB-6ALS Power Supply
The VBB Series power supplies are efficient high performance switching power supplies with battery charger and power supervision, capable of providing two outputs, user selectable for 12 or 24 VDC. One output provides continuous output power and the second is programmable to either fail-safe or fail-secure lock operation, when the on board fire alarm interface is activated. On-board visual indicators allow for immediate installer feedback. Independent form C relay contacts are provided to report AC and system fault conditions to remote or auxiliary equipment. The VBB Series are uninterruptible power supplies when stand-by batteries are connected. VBB power supplies are fully fault protected and feature fiberglass printed circuit boards to protect the electronics from water and other corrosive elements. High efficiency design promotes low heat generation leading to longer service life. These power supplies are RoHs compliant, lead-free, and meet the latest state, federal and European requirements for energy efficiency.
- Status indicating LEDs provide rapid indication of critical operating parameters.
- For use with VBB or VLB Controller
- User selectable voltage - Continuous or switched
- Fire Alarm Interface - User programmable fail-safe or fail-secure operation
- Battery Charging - Independent charging circuit meets stricter UL output tolerance requirements
- Microprocessor dual rate charging restores battery sets from 4 to 40 Ah
- Automatic switch over to battery when AC fails
- Zero voltage dropout on battery transfer
- Over load protection / short circuit protection
- Over temperature protection
Product Type: Power Supply
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Series: VBB
Brand Name: ComNet
Manufacturer: ACRE
Product Model: VBB-6ALS
Product Name: VBB-6ALS Power Supply
Manufacturer Part Number: VBB-6ALS
Manufacturer Website Address: http://www.acre-co.com
Package Contents:
- VBB-6ALS Power Supply
- Installation Manual
- Product CD
Limited Warranty: 3 Year
Weight (Approximate): 11.50 lb
