This 4K presentation matrix switch is perfect for conference rooms, boardrooms, and presentation environments that need seamless true 4K video distribution. Our ATEN VP1420 delivers:
-
Professional presentation system that supports multiple source switching to dual displays
-
4K HDMI matrix switch functionality for crystal-clear video quality
-
Conference room equipment compatibility ensuring reliable AV connectivity
-
Video switching solutions for enhanced meeting productivity and collaboration
Key Features
-
True 4K resolution support at 4096 x 2160 @ 30Hz for stunning visual clarity
-
4 x 2 matrix configuration enabling four input sources to two display outputs
- HDCP 2.2 compliant for secure content protection
- Auto-sensing technology for seamless presentation switching
- Front panel push buttons and IR remote control for flexible operation
- Compatible with ATEN presentation systems and third-party devices
-
Professional-grade construction for reliable conference room deployment
Technical Specifications
| Manufacturer |
ATEN TECHNOLOGIES |
| Model Number |
VP1420 |
| Type |
4K Presentation Matrix Switch |
| Configuration |
4 Input × 2 Output |
| Maximum Resolution |
True 4K (4096 x 2160) @ 30Hz, UHD (3840 x 2160) @ 60Hz |
| HDCP Support |
HDCP 2.2 compliant |
| Input Connectors |
4 × HDMI (Type A, 19-pin female) |
| Output Connectors |
2 × HDMI (Type A, 19-pin female) |
| Control Methods |
Front panel buttons, IR remote, RS-232 |
| Power Consumption |
16W maximum |
| Compatible Systems |
ATEN presentation solutions, Windows, macOS, Linux systems |
| Operating Temperature |
0 to 40°C (32 to 104°F) |
| Dimensions |
430 × 132.6 × 44 mm (16.93 × 5.22 × 1.73 inches) |
Frequently Asked Questions
Q: What makes this different from a standard HDMI switch?
A: The VP1420 is a presentation matrix switch that allows any of the 4 input sources to be routed to either or both output displays simultaneously, providing flexible video distribution for conference rooms.
Q: Does this support 4K resolution at 60Hz?
A: Yes, it supports UHD 4K resolution (3840 x 2160) at 60Hz and True 4K (4096 x 2160) at 30Hz with HDCP 2.2 compliance for protected content.
Q: Can I control this remotely for presentation environments?
A: Absolutely. The VP1420 includes IR remote control, RS-232 connectivity for automation systems, and front panel controls — perfect for professional presentation systems and meeting room installations.
Q: Is this compatible with existing AV equipment?
A: Yes. This HDMI matrix switch works with all HDMI-enabled devices including laptops, media players, document cameras, and display systems commonly used in conference room setups.
Professional 4K HDMI matrix switch for presentation systems. True 4K video distribution with flexible routing and conference room compatibility.
