Microchip 4 + 1 Outdoor Switch, 60W Per Port, Managed PoE, AC Input
The PDS-104GO is an outdoor PoE switch that enables the connection of four powered devices to a network such as an outdoor WLAN, outdoor IP camera, or outdoor P2P radio. With VLAN and RADIUS support, the PDS-104GO brings improved security and performance. It provides better safety through centralized management of user profiles and authorized system access. By regulating network traffic in each VLAN, the switch offers increased network performance. The switch offers an SFP port for uplink in order to support optical interfaces or electrical interfaces. It is IP66-rated and can be installed in outdoor environments. There is no need to open the unit during installation. Deployment is simple and straightforward. The PDS-104GO delivers PoE power of up to 60W per device. In addition, it enables remote monitoring and control of the devices' status, including remote reset. The switch extends the reach between the switch and powered devices by an additional 100 meters, to a maximum of 200 meters-a major benefit in many applications. It offers lightning protection to the switch itself and to the indoor network.
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 4 ports
- Cascade to other network devices through the uplink port to expand your local area network
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Gigabit Ethernet port for ultra-fast network speeds
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Management capability provides control over setup and configuration of your network
- No need to deal with power supply issues, the switch comes with a separate AC adapter to power up the unit
Product Type: Ethernet Switch
Country Of Origin: Philippines
Brand Name: Microchip
Manufacturer: Microchip Technology Inc.
Product Model: PDS-104GO
Product Name: 4 + 1 Outdoor Switch, 60W Per Port, Managed PoE, AC Input
Manufacturer Website Address: http://www.microchip.com
Weight (Approximate): 6.39 lb
