WyreStorm KVM Console/Extender
Although WyreStorm have offered 5Play compliance over Class A HDBaseT for some time, the EX-100-4K-PRO takes things a step further with the arrival of HDBaseT 2.0.
An HDMI extender set literally bursting at the seams with features, the EX-100-4K-PRO is one of the first extenders in the world to feature HDBaseT 2.0 specification; HD video, audio, Ethernet, two-way control via IR and Serial and two-way PoH over distances of 100m/328ft for full 4K or 150m/492ft at 1080p along a single Cat6 cable.
Unrivalled power, distance and functionality, the EX-100-4K-PRO represents the ultimate 4K extender solution supporting UltraHD 4K resolutions at 60Hz with chroma subsampling of up to 4:2:0 offering support for new 4K broadcast standards.
2-way PoH allows either transmitter or receiver to be powered. Both the TX & RX feature dual 10/100 Ethernet ports for connection of up to 3 devices + LAN per extender pair. The addition of USB 2.0 pass-through offers KVM functionality while enabling full data transfer capabilities. Either end may be connected to the host or dual devices and DIP switch management allows for the direction of USB control, long cable mode and firmware updates to the units.
The EX-100-4K-PRO includes audio embed on transmitter and de-embed on the receiver via 3.5mm jack connectivity. Separate audio feeds can also be directed bi-directionally thanks to an additional two-way S/PDIF audio pass-through that allows digital audio signals to be sent and received at either end.
Supporting the latest 4K standards yet also backwards compatible with HDBaseT 1.0 transmitters or receivers, the EX-100-4K-PRO is ready and primed for the 4K future, yet still compatible with current technology versions for arguably the most powerful and fully-featured HDBaseT extender on the market.
Product Type: KVM Console/Extender
Transmitter Height: 0.79"
Transmitter Width: 10.70"
Transmitter Depth: 3.89"
Receiver Height: 0.79"
Receiver Width: 10.70"
Receiver Depth: 3.89"
Brand Name: WyreStorm
Manufacturer: WyreStorm
Product Name: KVM Console/Extender
Manufacturer Part Number: EX-100-4K-PRO
Manufacturer Website Address: http://www.wyrestorm.com
Package Contents:
- 1 x EX-100-4K-PRO Transmitter
- 1 x EX-100-4K-PRO Receiver
- 1 x 12V DC 2A Power Supply (US/UK/EU)
- 2 x 2-pin Screw Down Phoenix Connectors
- 2 x 3-pin Screw Down Phoenix Connectors
- 2 x IR Emitters
- 2 x Wide-band IR Receivers (30-50KHz)
- 4 x Mounting Brackets (1pr for TX and 1pr for RX)
- 1 x Quickstart Guide
Limited Warranty: 3 Year
