Promise VTrak J5320s Drive Enclosure - Mini-SAS HD Host Interface - 2U Rack-mountable
VTrak J5000 Series
VTrak JBOD expansion units for cloud and enterprise data centers
Affordable Enterprise-Level Storage
The VTrak J5000 Series delivers an affordable high performance SAS solution with advanced enterprise level reliability and functionality. The four external 12 Gb/s SAS ports per I/O module provide the connectivity for large capacity solutions requiring multiple cascaded JBODs, and high bandwidth solutions requiring speed. It features fully redundant I/O modules, power supplies and cooling units, combined with a cable-less system design, providing exceptional data availability even during component failures for the enterprise environment.
Supports Hybrid HDD/SSD Arrays
Fully backward compatible with 6 Gb/s SAS/SATA devices, users have the ability to deploy 3 Gb/s, 6 Gb/s, and 12 Gb/s SAS/SATA HDDs and SSDs in the J5000 Series. Efficient power supplies provide up to 90% power efficiency, which improves TCO by conserving power, reducing heat output, and improving cooling costs. The internal 12 Gb/s SAS expander-based architecture also allows for transparent access to each drive, enabling full utilization of the power management features built into modern hard drives.
Increased Performance To Optimize Datacenters
The VTrak J5000 Series moves data at incredible speeds, allowing you to optimize your datacenter. Administrators can deploy with the fastest SAS bus speed with 12 Gb/s HDDs or SSDs. These systems are fully backward compatible with 6 Gb/s SAS/SATA drives, yet are still able to optimize the full port bandwidth of 12 Gb/s to the host. Flash arrays allow you to optimize speed for key enterprise apps that require utmost performance. The internal 12 Gb/s SAS expander-based architecture allows for data to transfer faster with greater redundancy protection.
- Flexible wide-port configuration: Four x4 wide ports, two x8 wide ports or one x16 wide port per IOM and SES-2 compliant enclosure management
- Dual active/active SAS JBOD I/O modules provide redundant data paths to ensure data availability and redundant hot-swappable Field Replaceable Units (FRUs)
- Supports SAS and SATA drives simultaneously and is compatible with leading SAS & SATA drives, HBAs, and RAID controllers
- 24 hot-swappable 2.5" (SFF) drive bays in a high-density 2U chassis
- VTrak J5000 Series 12 Gb/s SAS subsystems deliver a high-performance SAS solution with advanced enterprise level reliability and functionality
Product Type: Drive Enclosure
Environmentally Friendly: Yes
Environmental Certification: RoHS
Product Series: J5000
Rack Height: 2U
Brand Name: Promise
Form Factor: Rack-mountable
Manufacturer: Promise Technology
Product Model: J5320s
Product Name: VTrak J5320s Drive Enclosure
Product Line: VTrak
Manufacturer Part Number: J5320SDSS2
Manufacturer Website Address: http://www.promise.com
Limited Warranty: 3 Year
Weight (Approximate): 42.33 lb
